The antenna V2, which uses passive (battery-free) UHF RFID technologies, is designed specially for easy connection to the upgradeable SPECTRE readers. Up to four antennas can be connected. Its high performances and circular polarization read field enable the antenna to meet the demands for long-distance identification required by vehicle or driver identification applications (access control for stationary or moving vehicles, automated vehicle authorization systems in car parks, fleet management, etc.).
UHF
Up to 14 m / 45.9 ft with the ETA v2 label and the TeleTag® windscreen tag depending on vehicle type and installation conditions
Black
25°C to + 60°C / - 13°F to + 140°F
Certified IP66 -Weather-resistant with waterproof electronics / Humidity: 5 - 95%
ISO18000-63 / EPC1 Gen 2 - 2 versions: low band 865 - 868 MHz / high band 902 - 928 MHz / Certifications: CE, ETSI, FCC Part 15, UL
Antenna: ABS and polycarbonate (ABS-PC)
(h x w x d): 348.7 x 279.2 x 45.1 mm / 13.7’’ x 11’’ x 1.8’’ (general tolerance following ISO NFT 58-000 standard
Reinforced vandal-proof structure IK10
